Promax Bell Mouth Tinned Copper Cable Lugs

Promax Bell Mouth Tinned Copper Cable Lugs

Key Features

• Tin plating significantly enhances both mechanical and electrical performance
• Half-moon inspection hole provides visual confirmation that the cable has been installed correctly when crimping
• Bell mouth shape enables easy insertion of flexible, fine stranded conductor
• Clear marking on barrel indicates correct crimping
• Annealed copper barrel maximises crimping properties
• Tin plating helps resist corrosive enviornmnets such as oil and gas, marine, petrochemicals and water industries

Cable lugs available are displayed below. Other sizes are available on request, please contact our team - 0800 699 353

Code	Cable Size	Eyelet Size	Lug Diameter (ID)
203862	10mm²	10mm	4.7mm
203727	16mm²	8mm	5.5mm
200328	16mm²	10mm	5.5mm
203728	25mm²	8mm	7.1mm
200329	25mm²	10mm	7.1mm
203731	25mm²	12mm	7.1mm
203729	35mm²	8mm	8.2mm
202021	35mm²	10mm	8.2mm
203732	35mm²	12mm	8.2mm
203730	50mm²	8mm	9.5mm
200330	50mm²	10mm	9.5mm
203733	50mm²	12mm	9.5mm
200331	70mm²	10mm	11.2mm
203734	70mm²	12mm	11.2mm
