ETC PH400 Supradur 400 Electrodes

ETC PH400 Supradur 400 Electrodes

Key Features

• SUPRADUR 400 is a think rutile coated MMA electrode for hardfacing applications
• Very easy to use
• Weld metal hardness of ~240 - 290HV10 in the as-welded condition, it can reach 400HV after water-quenching
• Deposit a maximum of 3 layers
• Used for surfacing against sliding impact, e.g. slideways, shock, e.g. cams and rolling impact, e.g. rotors
• Typical applications are civil works and agricultural equipment such as crane parts, rails, slideways, rope pulleys, track-support rollers of crawler-type vehicles, wheel flanges and stud links
• Electrodes are approx 450mm long
• Available in 4mm (approx. 115 electrodes per pack) and 5mm (approx. 80 electrodes per pack) diameter
